Water Meters DA 150
In busy commercial bakeries, every baker must multitask. We made the DA 150 for the baker who needs remote control dependability on water volume and temperature — and has no time to monitor delivery. The DA 150 delivers up to 100 lbs. of water per minute. When paired with the (optional) Thermostatic Mixing Valve, this water is delivered at the right temperature for your recipe.
Download BrochureEasy to Control
Our Sigma agitator gently rotates and moves the dough mass from each end of the bowl to the center – and back again – in a continuous mixing action with a minimum of heat rise in the dough. The result? Homogeneous distribution of ingredients efficiently achieved.
Temperatures Up to 120° F. Accurate & Dependable
The DA 150 is an accurate bakery water meter that can deliver water in temperatures up to 250° and is accurate to within +/- 1% when running at 100 lbs./min.
Want to download or print more information about our Water Meters DA 150?
Click the button below to open the .pdf document. You can then download and print the detailed information!
Open Detailed Information Sheet
Water Meters SDWM
Designed for the retail baker who produces multiple and varied batches of product per day, the CMC-America SDWM places up to 100 Lbs. per minute of water. When paired with an optional Thermostatic Mixing Valve, the SDWM provides the baker with both weight/volume and temperature control. The SDWM attaches to ¾” NPT water lines and provides output temperatures ranging from 40° – 90° F, 65° – 115° F and 85° – 160° F at full accuracy starting at 1/10 lbs. of volume. The unit is easy-to-use for bakers who want to give every batch that personal, hands-on touch.
Download BrochureSanitary Construction for Your Most Important Ingredient – Water.
The basic meter is made with non-corrosive bronze parts and the entire unit is rust-less and non-corrosive. Water is delivered through an 8’ stainless steel flexible hose.
Compact & Easy to Install in Your Bakery
The standard SDWM measures 12” W – 16” H – 7” D. When combined with the Thermostatic Mixing Valve, the unit measures 22” W – 16” H – 7” D. Weighing 55 lbs. with an Aluminum enclosure mounting bracket, the SDWM is compact and easy to install.
It Works. It Never Stops.
With only one working part in the SDWM chamber, sustained, trouble-free accurate bakery water meter performance is ensured. The unit’s laminated fiber piston is not subject to breakage. It has positive displacement for exact measurement. With geared accuracy adjustment, no bypass arrangement is needed.
Want to download or print more information about our Water Meters SDWM?
Click the button below to open the .pdf document. You can then download and print the detailed information!
Open Detailed Information Sheet
Water Meters Industrial Grade D 150 & D 300
CMC-America’s industrial water meters, the D 150 & D 300 are designed to keep industrial dough operations at maximum efficiency. These units deliver up to 150 lbs. per min and up to 300 lbs. per min respectively. Higher output meters can be manufactured upon request. When paired with the optional Thermostatic Mixing Valve, your operation will have complete control of both the volume and the temperature of the water going into your recipes.
Download BrochureRemote Control. Completely Automatic
The meter control panel can be placed anywhere. It need not be located adjacent to the water source. To use, just set the volume of water you need and press ‘start’. The exact amount will be delivered. Shut off is automatic with an electric solenoid shut off valve, and the unit comes with a built-in thermometer.
Available with Exclusive Thermostatic Control
If you install the optional thermostatic mixing valve, the unit will deliver water at exact temperatures at high volumes. It is accurate to within 1/2° F. Once set, the unit will deliver water at the desired temperature, mix after mix.
Sanitary. Dependable. Service-Tested
The meter is made of non-corrosive bronze parts and contains a bronze strainer to eliminate scale and other water-borne sediments. It is easily removed for cleaning. Its synthetic disc, ball and pin provide dependable performance. If you want an accurate baking water meter, trust the D-150 or the D-300 to get the job done.
Want to download or print more information about our Water Meters Industrial Grade D 150 & D 300?
Click the button below to open the .pdf document. You can then download and print the detailed information!
Open Detailed Information Sheet
